مطمئنا همه دوستانی که حتی آشنایی مختصری با پردازش تصویر داشته باشن، اسم کتاب Digital Image Processing آقایان Gonzalez و Woods رو شنیدن و ممکنه ازش استفاده هم کرده باشن. همین دو نویسنده یه کتاب با عنوان Digital Image Processing Using Matlab هم به همراه جناب Eddins برای آموزش پردازش تصویر با متلب نوشتن. آقای Eddins هم از توسعه دهندگان متلب و تولباکس پردازش تصویر اون هستن، یه بلاگی هم روی سایت Mathworks.com دارن که مطالب جالب و کاربردی در مورد پردازش تصویر، پردازش سیگنال، تبدیل فوریه و خیلی مباحث دیگه رو اونجا توضیح میدن. کتاب رو هم از لینک زیر می تونین دانلود کنین:

در اینجا کدها و فانکشن هایی که داخل این کتاب تعریف شده رو برای دانلود قرار می دهیم.



لیست فانکشن ها:

در زیر هم می تونین لیست این فانکشن ها و توضیح مختصری در موردشون رو مشاهده کنین:

Function
Description
Image Display
ice Interactive Color Editor.
rgbcube Displays an RGB cube.
Geometric Transformations
pixeldup Duplicates pixels of an image in both directions.
vistform Visualization transformation effect on set of points.
Pixel Values and Statistics
covmatrix Covariance matrix of vector population.
statmoments Statistical central moments of image histogram.
Image Analysis
bayesgauss Bayes classifier for Gaussian patterns.
bound2eight Convert 4-connected boundary to 8-connected boundary.
bound2four Convert 8-connected boundary to 4-connected boundary.
bound2im Converts a boundary to an image.
bsubsamp Subsample a boundary.
bwboundaries Trace region boundaries.
colorgrad Vector gradient of an RGB image.
colorseg Segment of a color image.
connectpoly Connects vertices of a polygon.
diameter Measure diameter of image regions.
fchcode Freeman chain code of a boundary.
frdescp Fourier descriptors.
hough Hough transform.
houghlines Extract line segments using Hough transform.
houghpeaks Detect peaks in Hough transform.
houghpixels Image pixels associated with Hough transform bin.
ifrdescp Inverse Fourier descriptors.
imstack2vectors Extracts vectors from an image stack.
invmoments Invariant moments of image.
mahalanobis Mahalanobis distance.
minperpoly Minimum perimeter polygon.
polyangles Internal angles of polygon vertices.
princomp Principal-component vectors.
randvertex Randomly perturb polygon vertices.
regiongrow Segmentation by region growing.
signature Signature of a boundary.
specxture Spectral texture of an image.
splitmerge Segment an image using split-and-merge.
statxture Statistical texture measures of image.
strsimilarity Similarity measurement between two strings.
x2majoraxis Aligns coordinate x with the major axis of a region.
Image Compression
compare Computes and displays the error between two matrices.
entropy Estimate entropy of a matrix.
huff2mat Decodes a Huffman encoded matrix.
huffman Builds Huffman code for a symbol source.
im2jpeg Compress an image using a JPEG approximation.
im2jpeg2k Compress an image using a JPEG 2000 approximation.
imratio Byte ratio for two image files or variables.
jpeg2im Decompress an IM2JPEG-compressed image.
jpeg2k2im Decompress an IM2JPEG2K-compressed image.
lpc2mat Decompresses lossless predictive encoded matrix.
mat2huff Huffman encodes a matrix.
mat2lpc Compresses a matrix using lossles predictive coding.
quantize Quantize the elements of a UINT8 matrix.
Image Enhancement
gscale Scale intensity values of image.
intrans Performs several intensity transformations.
Image Noise
imnoise2 Generate random array using specified PDF.
imnoise3 Generates periodic noise.
Linear and nonlinear spatial filtering
adpmedian Adaptive median filtering.
dftcorr Frequency-domain correlation.
dftfilt Frequency domain filtering.
spfilt Linear and nonlinear spatial filtering.
Linear 2-D Filter Design
hpfilter Frequency domain highpass filters
lpfilter Frequency domain lowpass filters.
Morphological Operations (Binary Images)
endpoints End-points of binary image.
Region-Based Processing
histroi Histogram of ROI in an image.
Wavelets
wave2gray Display wavelet decomposition coefficients.
waveback Multilevel 2-D inverse fast wavelet transform.
wavecopy Fetch coefficients of wavelet decomposition.
wavecut Set to zero coefficients of wavelet decomposition.
wavefast Multilevel 2-D fast wavelet transform.
wavefilter Wavelet decomposition and reconstruction filters.
wavepaste Put coefficients into wavelet decomposition.
wavework Edit wavelet decomposition structure.
wavezero Set wavelet detail coefficients to zero.
Color Space Conversions
hsi2rgb Convert HSI values to RGB color space.
rgb2hsi Convert RGB values to HSI color space.
Array Operations
dftuv Mesgrid frequency arrays.
paddedsize Recommended pad size for FFT-based filtering.
Miscellaneous
conwaylaws Apply Conway’s genetic laws to a pixel.
manualhist Generate 2-mode histogram interactively.
twomodegauss Generate 2-mode Gaussian function.
unravel Utility MEX-file used for Huffman decoding.
Functions used only for illustration in the book
average Average value of array.
fwtcompare Compare DIPUM and Wavelet Toolbox FWT functions.
gmean Geometric mean of columns.
ifwtcompare Compare DIPUM and Wavelet Toolbox IFWT functions.
improd Product of two images.
subim Extract subimage.
twodsin Compare loop vs. vectorized implementation.
Undocumented IPT functions
changeclass Scale image and change its class.
intline Integer-coordinate line-drawing algorithm.



DIPUM Toolbox.
Version 1.1.4 15-July-2006
M-files from the book Digital Image Processing Using MATLAB, by
R.C. Gonzalez, R.E. Woods, and S.L. Eddins, Prentice Hall, 2004.
برای دانلود به لینک زیر مراجعه کنید:
